IP PBX Features

• 50 account (extensions)
• 12 SIP Trunk
• Registration and authentication
• BLF (Busy-lamp Field)
• Hunting Group
• IVR
• Calendar
• Dial Plan (Digit Map)
• Session Monitor
• Call Detail Records
• DID
• Extension Privilege Assign
• PIN Code Control
• Call Barring, Call Park , Call Pickup
• In/Outbond Call Through FXO Interface
• In/Outbond Call Through External ATA Gateway Interface (Custom Trunks x8)
• User-defined Prompts / Automated Attendant
• MWI (Message Waiting Indicator)
• Voice Message to Email
• Music on Hold
• Internet Extension White List / Auto Blocking (Password Attacking)
• Virtual FAX

VDSL2/ADSL2/2+ modem

• ITU-T G.993.2 (VDSL2)
• ITU-T G.992.1/3/5 (ADSL1/2/2+) Annex A & Annex B
• DSL Forum Performance Specification: ADSL TR-048/67, TR-100; VDSL: WT-114
• Erasure Decoding, Increased Interleaver Depth and Re-transmission
• EFM (IEEE 802.3 ah)
• VDSL2 Profile: up to 30a

WAN Protocol

• DSL (WAN-1)/Giga Ethernet (WAN-2)
  • DHCP Client
  • Static IP
  • PPPoE
  • PPTP/L2TP (WAN-2 only)
  • PPPoA (ADSL2 only)
  • 802.1q Multi-VLAN Tagging
• USB (WAN 3/WAN 4)
  • PPP/DHCP
• IPv6
  • Tunnel Mode: TSPC, AICCU, 6rd, Static 6in4
  • Dual Stack: PPP, DHCPv6 Client, Static IPv6

USB

• 3G/LTE (HSDPA) as WAN 3/WAN 4
• Printer Sharing
• File System
  • Support FAT32 File System
  • Support FTP Function for File Sharing
  • Support Samba for File Sharing
• LTE USB mobile Support List Please Contact

VPN

• Up to 32 VPN Tunnels
• Protocol : PPTP, IPsec, L2TP, L2TP over IPsec
• Encryption : MPPE and Hardware-based AES/DES/3DES
• Authentication : MD5, SHA-1
• IKE Authentication : Pre-shared Key and Digital Signature (X.509)
• LAN-to-LAN, Teleworker-to-LAN
• DHCP over IPsec
• IPsec NAT-traversal (NAT-T)
• Dead Peer Detection (DPD)
• VPN Pass-through
• VPN Wizard
• mOTP
• SSL VPN: 16 Tunnels
• VPN Trunk (Load Balance/Backup)

Multi-WAN

• Load-Balance/Route Policy
  (The VDSL2/ADSL2+ interface, Gigabit Ethernet interface, LTE modem and USB mobile can be used either for WAN-backup or load balancing.)
• WAN Connection Failover

CSM (Content Security Management)

• IM/P2P Application
• GlobalView Web Content Filter (Powered by )
  • URL Content Filter :URL Keyword Blocking (Whitelist and Blacklist)
  • Java Applet, Cookies, Active X, Compressed, Executable, Multimedia File Blocking
  • Excepting Subnets

Bandwidth Management

• QoS
  • Guarantee Bandwidth for VoIP
  • Class-based Bandwidth Guarantee by User-defined Traffic Categories
  • DiffServ Code Point Classifying
  • 4-level Priority for Each Direction (Inbound/Outbound)
  • Bandwidth Borrowed
• Bndwidth/Session Limitation
• Layer-2 (802.1p) and Layer-3 (TOS/DSCP) QoS Mapping

Network Feature

• Packet Forwarding Acceleration*
• DHCP Client/Relay/Server
• IGMP Snooping/Proxy V2 and V3
• Triple-Play Application
• Dynamic DNS
• NTP Client
• Call Scheduling
• RADIUS Client
• DNS Cache/Proxy and LAN DNS
• UPnP 30 sessions
• Multiple Subnets
• Port-based/Tag-based VLAN (802.1q)
• Routing Protocol :
  • Static Routing
  • RIP V2

Network Management

• Web-based User Interface (HTTP/HTTPS)
• Quick Start Wizard
• CLI (Command Line Interface, Telnet/SSH)
• Administration Access Control
• Configuration Backup/Restore
• Built-in Diagnostic Function
• Firmware Upgrade via TFTP/FTP/HTTP/TR-069
• Logging via Syslog
• SNMP Management MIB-II
• Management Session Time Out
• 2-level Management (Admin/User Mode)
• TR-069
• TR-104
• LAN Port Monitoring
• Support Smart Monitor (50-nodes)

Firewall

• Multi-NAT, DMZ Host, Port-redirection and Open Port
• Object-based Firewall, Object IPv6, Group IPv6
• MAC Address Filter
• SPI (Stateful Packet Inspection) (Flow Track)
• DoS Prevention
• IP Address Anti-spoofing
• E-mail Alert and Logging via Syslog
• Bind IP to MAC Address
• Time Schedule Control
• User Management

Wireless AP

• 802.11ac WLAN
• Wireless Client List
• Wireless LAN Isolation
• 64/128-bit WEP
• WPA/WPA2
• Wireless Wizard
• Hidden SSID
• WPS
• MAC Address Access Control
• Access Point Discovery
• WDS (Wireless Distribution System)
• 802.1x Authentication
• Multiple SSID
• Wireless Rate-control
• IEEE802.11e: WMM (Wi-Fi Multimedia)
• SSID VLAN Grouping with LAN Port (Port-based VLAN)
