Manufacturer:

Cisco

Product ID:

CISCO1841-SEC/K9

Product Description:

1841 Security Bundle, Adv.Security, 64FL/256DR

Product Type:

Router

Interfaces/Ports

Total Number of Ports:

2

USB:

Yes

Management Port:

Yes

Number of Network (RJ-45) Ports:

2

I/O Expansions

Number of Total Expansion Slots:

3

Expansion Slot Type:

AIM

Network & Communication

Network Technology:

10/100Base-TX

Ethernet Technology:

Fast Ethernet

Management & Protocols

Security Features:

• Secure Shell (SSH)
• Easy VPN Client and Server
• Dynamic Multipoint VPN (DMVPN)

Encryption support in software and hardware:

• DES, 3DES, AES 128, AES 192, AES 256
• Threat Defense:
• Cisco IOS Firewall
• Transparent Firewall
• Intrusion Prevention
• URL Filtering

Trust and Identity:

• Network Admission Control (NAC)
• Authentication, Authorization, and Accounting (AAA)
• 802.1x Support

Memory

Standard Memory:

256 MB

Maximum Memory:

384 MB

Memory Technology:

DRAM

Flash Memory:

64 MB

Power Description

Input Voltage:

110 V AC

220 V AC

Power Source:

Power Supply

Physical Characteristics

Form Factor:

Desktop

Wall Mountable

Height:

1.7"

Width:

13.5"

Depth:

10.8"

Weight (Approximate):

6 lb

Miscellaneous

Package Contents:

• 1841 Router
• Cisco 1841 IOS ADVANCED SECURITY
• Device manager for routers (ROUTER-SDM)
• 64MB Cisco 1800 Compact Flash Memory (MEM1800-64CF)
• 128 to 256MB SODIMM DRAM factory upgrade for the Cisco 1841 (MEM1841-128U256D)
• Blank WAN Interface Card Panel (WIC-BLANK-PANEL)
• One blue RJ-45-to-DB-9 console cable
• One DB-9-to-DB-25 modem adapter
• Power Cord
• Cisco product registration card
• Regulatory Compliance and Safety Information for Cisco 1840 Routers document
• Cisco Router and Security Device Manager (SDM) Quick Start Guide document
• Cisco 1800 Series Integrated Services Routers (Modular) Quick Start Guide

Additional Information:

Interface Card Slots:

• Both slots on the Cisco 1841 router are HWIC slots and provide compatibility with WICs and multiflex trunk (VWICs) interface cards (for data only)

VoIP support:

• Voice-over-IP (VoIP) pass-through only

Operating altitude:

• 10,000 feet (3000 meters) @ 77°F (25°C)

Noise level:

• Normal operating temperature:
• >78°F/25.6°C through
• >104°F/40°C: 42 dBA

Certifications & Standards:

• IEEE 802.3: 10BASE-T
• IEEE 802.3u: 100BASE-TX
• IEEE 802.1x: Authentication
• USB 1.1

Safety:

• UL60950-1
• CAN/CSA 60950-1
• AS 3260
• EN60950-1

EMI:

• EN 55022, 1998, class A
• CISPR22, 1997, class A
• CFR47, Part 15, Subpart B, 1995, class A
• EN61000-3-2 Harmonic Current Emission (only for equipment >75W but
